H-Frame Set
Rigid welded H-frame assemblies for rapid high-rise access & masonry.
H-Frame Set Manufacturer & Supplier | Sharnam Infra
H-Frame Scaffolding Sets consist of two prefabricated welded steel frames connected by scissor-style cross bracings. They provide an extremely stable, quick-to-erect access tower system for brickwork, facade plastering, painting, and glazing installation.
Built with integrated ladder rungs and gravity lock drop pins, H-Frame sets enable safe vertical worker movement and provide high load-bearing support for stacked working platforms.
Durable H-Frame Set Manufacturer & Supplier | Sharnam Infra
Sharnam Infra Solutions is a leading manufacturer and supplier of sturdy, durable h-frame set across major industrial and commercial construction sectors. Our equipment undergoes rigorous three-level quality control — at production, warehousing, and before loading — ensuring unmatched reliability. We design and manufacture tailor-made solutions suited for your site requirements.
H-Frame Set Technical Specifications & Load Ratings
| SPECIFICATION PARAMETER | RATING / VALUE |
|---|---|
| Frame Heights | 1500mm / 2000mm |
| Frame Widths | 1000mm / 1250mm |
| Main Tube OD | 48.3mm x 2.75mm WT |
| Brace Lengths | 1.8m / 2.5m Scissor Braces |
| Safe Working Load | 25 kN per tower legs |
| Standard Finish | Powder Coated / Galvanized |
H-Frame Set Component Variations & Head Attachments
H-Frame Set - Standard Heavy Duty
H-Frame Set - U-Head Attachment
H-Frame Set - Galvanised Finish
H-Frame Set - Custom Base & Nut
